Collection: Arrowhead Brass 490 Series Vertical Hot And Cold Faucet Parts

The ABP 490V Vertical Faucet hot and cold vertical self-draining frost-proof hydrants have a variety of inlet options to meet your needs. Also, The 490V series includes Arrowhead Brass’s exclusive O-ring bonnet and stem design (no packaging nut to tighten) and a 3-year limited warranty.

490V features: ABP 490V Vertical Faucet

Made from a heavy duty, lead free bronze alloy
Factory installed fine thread self draining vacuum breaker allows hydrant to drain when shut off to prevent freezing
Arrow-Breaker® built in anti siphon backflow protection: ASSE1019-A approved, IAPMO certified
Dual vertical inlets with red and blue oval handles to regulate flow temperature
Also Available in 2”, 4”, 6”, 8”, 10”, 12”, and 14” lengths
Inlet Connection: various options
Outlet Connection: ¾” hose thread
Also Lead-free certified to NSF/ANSI 372 (by IAPMO)
3-year limited warranty
Max pressure: 125 PSI
Max temperature: 180o F
Also available with lockshield and loose key
Available Base Models*: ABP 490V Vertical Faucet
491-XXVLF: Hot & Cold Frost-Proof Also Anti-Siphon Vertical Wall Hydrant with 3/4″ Uponor (PEX A) inlet
492-XXVLF: Hot & Cold Frost-Proof Also Anti-Siphon Vertical Wall Hydrant with 1/2″ Uponor (PEX A) inlet
495-XXVLF: Hot & Cold Frost-Proof Also Anti-Siphon Vertical Wall Hydrant with 1/2″ Female Iron Pipe Thread & 3/4″ Male Iron Pipe Thread
496-XXVLF: Hot & Cold Frost-Proof Anti-Siphon Vertical Wall Hydrant with 1/2″ Male Iron Pipe Thread & 1/2″ Copper Sweat
497-XXVLF: Hot & Cold Frost-Proof Anti-Siphon Vertical Wall Hydrant with 3/4″ PEX inlet
498-XXVLF: Hot & Cold Frost-Proof Anti-Siphon Vertical Wall Hydrant with 3/4″ Female Iron Pipe Thread & 3/4″ Copper Sweat
499-XXVLF: Hot & Cold Frost-Proof Anti-Siphon Vertical Wall Hydrant Also with 1/2″ PEX inlet

*Specify “XX” = “04”, “06”, “08”, “10”, “12”, or “14” hydrant length.
